ACER AGS-1230AHD
ACER AGS-1230AHD

New equipment · ACER

ACER Surface Grinders

Model: ACER AGS-1230AHD

$35,700.00 USD

Manufacturer list price for the standard machine. Freight, tax and optional equipment are quoted separately.

Bay Area CNC Machinery · Authorized ACER dealer

The AGS-1230AHD is a precision surface grinder from ACER. Table / work size: 12 × 30 in grinding surface. Longitudinal travel: 33.1 in.

  • Cross travel: 13.1 in
  • Spindle center to table: 23-1/2 in
  • Spindle motor: 5 HP
  • Wheel speed: 1,750 rpm
Email Bay Area CNC Call (925) 256-8111

Confirm current configuration, availability and freight with Bay Area CNC. Prices are based on FOB Fullerton, California.

Specifications

ACER AGS-1230AHD
ACER AGS-1230AHD specifications
Table / work size12 × 30 in grinding surface
Longitudinal travel33.1 in
Cross travel13.1 in
Spindle center to table23-1/2 in
Spindle motor5 HP
Wheel speed1,750 rpm
Grinding wheel (diameter × width × bore)14 × 1-1/4 × 5 in
Net weight4,290 lbs
