ACER Vertical Machining Centers
Model: ACER VMC-2451 · Fagor
Request a Quote USD
Contact Bay Area CNC for current pricing and configuration.
Bay Area CNC Machinery · Authorized ACER dealer
No matching model in this family. Try a shorter model number.
The VMC-2451 · Fagor is a vertical machining center from ACER. Table size: 52.7" x 23.6". Table load: 1,760 lbs.
- X travel: 51.1"
- Y travel: 24"
- Z travel: 23.6"
- Spindle speed: 60 ~ 8,000 rpm
Confirm current configuration, availability and freight with Bay Area CNC. Prices are based on FOB Fullerton, California.
Specifications
ACER VMC-2451 · Fagor| Table size | 52.7" x 23.6" |
|---|---|
| Table load | 1,760 lbs |
| X travel | 51.1" |
| Y travel | 24" |
| Z travel | 23.6" |
| Spindle speed | 60 ~ 8,000 rpm |
| Tool capacity | 24 pcs |
| Spindle motor (AC digital) | 10 HP (15 HP 30 min peak) |
| Net weight (approx.) | 17,680 lbs |
